Type 1 + 2 lab water system HALIOS 12
€9,345.00
- Product: Type 1 ultrapure water + Type 2 pure water
- Feed: tap/domestic water
- Dispense rate: 2 L/min
- Type 2 production rate: 12 L/h at 10°C, 15 L/h at 20°C
- Storage: Type 1 production on demand, Type 2: 10 L storage tank
- Dispenser: benchtop telescopic dispenser
Description
Halios 12: The All-in-One Lab Water Solution with tabletop dispenser
The Halios 12 is the ultimate laboratory water purification system, delivering both Type I Ultrapure Water and Type II Pure Water directly from tap water.
Water Production:
Type I/Ultrapure Water: For critical laboratory applications.
Type II/Pure Water: Produces 12l/h at 10°C and 15 l/h at 20°C for general lab use.
Storage capacity: standard 10l storage tank for Type II/Pure water. Optional 50l tank with dispensing gun.
Why Wait? Transform Your Lab Today
Discover the perfect ultrapure water solution tailored to your laboratory’s needs with HALIOS 12. Contact us now to request a quote, schedule a demo, or learn more about our cutting-edge laboratory water purification systems.
Specifications
Feed water requirements
| Feed water quality | Potable tap water |
| Feed water quality Conductivity at 25°C | < 2000 µS/cm |
| Total organic carbon (TOC) | < 1 ppm |
| Inlet pressure* | 1 – 6 bar |
| Temperature | 5 – 35 °C |
* Additional pre-treatment units are available if the feed water is out of specs
Ultrapure, Type 1 water specifications
| Resistivity at 25 °C | 18.2 MΩ∙cm |
| Total organic carbon (TOC) | ≤ 2 ppb
≤ 10 ppb (without UV) |
| Particles content | Particle-free (size > 0.22 µm) |
| Bacteria | < 0.01 CFU/mL
< 0.005 CFU/mL (with ultrafilter) |
| Pyrogens (endotoxins) | < 0.001 EU/mL (with ultrafilter) |
| RNases | < 0.004 ng/mL (with ultrafilter) |
| DNases | < 0.024 pg/µL (with ultrafilter) |
| Flow rate | adjustable up to 2 L/min |
Pure water specifications in the tank (ASTM type 2)
| Resisitivity (Conduct.) at 25°C | > 10MΩcm (<0,1µS/cm) |
| TOC | ≤ 30ppb (µg/l) |
| Performance | 12l/h at 10°C
15l/h at 20°C |
Technical data
| Ambient temperature | +2 – 35°C |
| Supply voltage | 90-240V / 50-60Hz |
| Connected load | 120W |
| Connection size | R ¾“ |
| Weight (complete) | 25kg |
Options and accessories
Options that can be integrated:
- 10001033 Ultrafiltration module + TOC monitor
- 10000455 EDI module for HALIOS
- 10000340 XXL dispenser (height +15 cm)
- 10000341 4m connection between dispenser and production unit (instead of 1.5m standard)
- 10000712 Upgrade – Pure water tank 50l incl. level sensor, circulation pump, sterile overflow, sterile vent filter + CO2 absorber,
- pressure outlet and dispensing gun (instead of 10l tank)
- 10000456 UVC-LED tank disinfection
Accessories:
- 10000104 Additional remote dispenser HALIOS – Type I (up to 3 additional)
- 10000704 Additional remote dispenser HALIOS – Type II (up to 3 additional)
- 10000105 Wall mount for production unit HALIOS
- 10000454 Wall mount for 10l tank
- 10000541 Wall mount for 50l tank
- 10000453 Wall mount for dispenser HALIOS
- 10000302 Qualification documents HALIOS 6 | 12
- 10000367 Water softener VD 8(pretreatment for poor feedwater)
- 10000480 External pressure pump 3m³/h at 3 bar
- 10000388 Disinfection kit HALIOS 6-40 incl. 3 disinfectants
